QUALITY CERTIFICATIONS: ISO 9001:2008 · ISO 13485:2003 · ISO 14001:2004 · OSHAS 18001:2007 · PPAP · FDA CRITICAL

PRECISION MINIATURE BALL BEARINGS–inch


	Standard Open BORE: .0400" to .3125" OD: .1250" to .5000"			Flanged Open BORE: .0400" to .3125" OD: .1250" to .5000"			Standard Shielded BORE: .0400" to .3125" OD: .1250" to .5000"			Flanged Shielded BORE: .0400" to .3125" OD: .1250" to .5000"

PRECISION MINIATURE BALL BEARINGS–metric


	Standard Open BORE: 1mm to 9mm OD: 3mm to 17mm			Flanged Open BORE: 1.2mm to 9mm OD: 4mm to 17mm		Standard Shielded BORE: 1.5mm to 9mm OD: 4mm to 22mm			Flanged Shielded BORE: 1.5mm to 9mm OD: 4mm to 17mm

PRECISION MINIATURE EXTENDED INNER RING–inch

Extended Inner
Ring Open
BORE: .0469" to .3125"
OD: .1562" to .6250"

Flanged Extended Inner Ring Open
BORE: .0469" to .3125"
OD: .1562" to .6250"

Extended Inner Ring Shielded
BORE: .0469" to .3125"
OD: .1562" to .6250"

Flanged Extended Inner Ring Shielded
BORE: .0469" to .3125"
OD: .1562" to .6250"

THIN SECTION BEARINGS–inch

High precision bearings ABEC 3 or ABEC 5 in stainless or 52100 chrome steel. Used in applications where there is limited clearance between shaft and housing.
		Thin Section Bearings BORE: .3750" to .7500" OD: .6250" to 1.000"

THRUST BEARINGS–metric

Thrust Bearings

Bore: 3mm to 10mm
OD: 8mm to 20mm

Stainless Steel Thrust Bearings
Bore: 3mm to 10mm
OD: 8mm to 20mm

INDUSTRIAL BEARINGS–inch & metric




Standard Radial Ball Bearings Bore: .1250" to .7500" OD: .3750" to 1.6250"	Radial Ball Bearings Bore: 10mm to 25mm OD: 19mm to 52mm	Flanged Radial Ball Bearings Bore: .1250" to .5000" OD: .3750" to 1.1250"	Flanged Radial Ball Bearings Bore: 10mm to 20mm OD: 19mm to 37mm

COLLAR & FLANGETTE BEARINGS–inch

Collar Bearings
Bore: .1875" to .5000"
OD: .6250" to 1.1250"

Flangette Collar Bearings
Bore: .2500" to .5000"
